9KQB | pdb_00009kqb

PSII-FCPII supercomplex from haptophyte Chrysotila roscoffensis

PDB DOI: https://doi.org/10.2210/pdb9KQB/pdb
EM Map EMD-62499: EMDB EMDataResource

Classification: PHOTOSYNTHESIS
Organism(s): Chrysotila roscoffensis
Mutation(s): No

Deposited: 2024-11-25 Released: 2025-05-07
Deposition Author(s): La Rocca, R., Kato, K., Tsai, P.-C., Nakajima, Y., Akita, F., Shen, J.-R.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.22 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Structure of a photosystem II-FCPII supercomplex from a haptophyte reveals a distinct antenna organization

La Rocca, R., Kato, K., Pi-Cheng, T., Nakajima, Y., Akita, F., Shen, J.R.

(2025) Nat Commun

DOI: https://doi.org/10.1038/s41467-025-59512-9

Macromolecule Content

Total Structure Weight: 977.75 kDa
Atom Count: 61,348
Modelled Residue Count: 5,822
Deposited Residue Count: 6,728
Unique protein chains: 20

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Fucoxanthin chlorophyll a/c binding protein II (FCPII-1)	A [auth 1], C [auth 7], NA [auth 5], OA [auth g]	166	Chrysotila roscoffensis	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Fucoxanthin chlorophyll a/c binding protein II (FCPII-5)	B [auth 6], J	167	Chrysotila roscoffensis	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II protein D1	D [auth A], R [auth a]	360	Chrysotila roscoffensis	Mutation(s): 0
UniProt
Find proteins for A0A7S4BZA9 (Chrysotila carterae) Explore A0A7S4BZA9 Go to UniProtKB: A0A7S4BZA9
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A7S4BZA9
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II CP47 reaction center protein	E [auth B], S [auth b]	509	Chrysotila roscoffensis	Mutation(s): 0
UniProt
Find proteins for Q4G3C5 (Emiliania huxleyi) Explore Q4G3C5 Go to UniProtKB: Q4G3C5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q4G3C5
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
Cytochrome b559 subunit alpha	F [auth E], T [auth e]	82	Chrysotila roscoffensis	Mutation(s): 0
UniProt
Find proteins for Q4G380 (Emiliania huxleyi) Explore Q4G380 Go to UniProtKB: Q4G380
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q4G380
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 6
Molecule	Chains	Sequence Length	Organism	Details	Image
Cytochrome b559 subunit beta	G [auth F], U [auth f]	42	Chrysotila roscoffensis	Mutation(s): 0
UniProt
Find proteins for Q4G381 (Emiliania huxleyi) Explore Q4G381 Go to UniProtKB: Q4G381
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q4G381
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 7
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein H (psbH)	H, V [auth h]	65	Chrysotila roscoffensis	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 8
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein I (psbI)	I, W [auth i]	38	Chrysotila roscoffensis	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 9
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein K (psbK)	K, X [auth k]	40	Chrysotila roscoffensis	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 10
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein L	L, Y [auth l]	38	Chrysotila roscoffensis	Mutation(s): 0
UniProt
Find proteins for D9MYJ9 (uncultured prymnesiophyte C19847) Explore D9MYJ9 Go to UniProtKB: D9MYJ9
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	D9MYJ9
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 11
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein M (psbM)	M, Z [auth m]	130	Chrysotila roscoffensis	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 12
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein Psb36	AA [auth n], N	36	Chrysotila roscoffensis	Mutation(s): 0
UniProt
Find proteins for A0A7S4C3N2 (Chrysotila carterae) Explore A0A7S4C3N2 Go to UniProtKB: A0A7S4C3N2
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A7S4C3N2
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 13
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein T	BA [auth t], O [auth T]	32	Chrysotila roscoffensis	Mutation(s): 0
UniProt
Find proteins for A0A3S6R2W1 (Tisochrysis lutea) Explore A0A3S6R2W1 Go to UniProtKB: A0A3S6R2W1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A3S6R2W1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 14
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein W (psbW)	CA [auth w], P [auth W]	53	Chrysotila roscoffensis	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 15
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein X (psbX)	DA [auth x], Q [auth X]	36	Chrysotila roscoffensis	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 16
Molecule	Chains	Sequence Length	Organism	Details	Image
Fucoxanthin chlorophyll a/c binding protein II (FCPII-2)	EA [auth 2], FA [auth 8]	225	Chrysotila roscoffensis	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 17
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II D2 protein	GA [auth D], HA [auth d]	351	Chrysotila roscoffensis	Mutation(s): 0 EC: 1.10.3.9
UniProt
Find proteins for Q4G395 (Emiliania huxleyi) Explore Q4G395 Go to UniProtKB: Q4G395
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q4G395
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 18
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II CP43 reaction center protein	IA [auth C], JA [auth c]	445	Chrysotila roscoffensis	Mutation(s): 0
UniProt
Find proteins for A0A075DWU3 (Chrysochromulina tobinii) Explore A0A075DWU3 Go to UniProtKB: A0A075DWU3
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A075DWU3
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 19
Molecule	Chains	Sequence Length	Organism	Details	Image
Light harvesting protein	KA [auth 9], LA [auth 3]	216	Chrysotila roscoffensis	Mutation(s): 0
UniProt
Find proteins for A0A7S4BJL5 (Chrysotila carterae) Explore A0A7S4BJL5 Go to UniProtKB: A0A7S4BJL5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A7S4BJL5
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 20
Molecule	Chains	Sequence Length	Organism	Details	Image
Fucoxanthin chlorophyll a/c binding protein II (FCPII-4)	MA [auth 4], PA [auth G]	167	Chrysotila roscoffensis	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 15 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
DGD (Subject of Investigation/LOI) Query on DGD Download Ideal Coordinates CCD File SDF format, chain CJ [auth C] SDF format, chain DG [auth h] SDF format, chain DJ [auth C] SDF format, chain QD [auth B] SDF format, chain TJ [auth c] SDF format, chain UJ [auth c] SDF format, chain WD [auth H] SDF format, chain ZE [auth b] MOL2 format, chain CJ [auth C] MOL2 format, chain DG [auth h] MOL2 format, chain DJ [auth C] MOL2 format, chain QD [auth B] MOL2 format, chain TJ [auth c] MOL2 format, chain UJ [auth c] MOL2 format, chain WD [auth H] MOL2 format, chain ZE [auth b] mmCIF format, chain CJ [auth C] mmCIF format, chain DG [auth h] mmCIF format, chain DJ [auth C] mmCIF format, chain QD [auth B] mmCIF format, chain TJ [auth c] mmCIF format, chain UJ [auth c] mmCIF format, chain WD [auth H] mmCIF format, chain ZE [auth b]	CJ [auth C] DG [auth h] DJ [auth C] QD [auth B] TJ [auth c] CJ [auth C], DG [auth h], DJ [auth C], QD [auth B], TJ [auth c], UJ [auth c], WD [auth H], ZE [auth b]	DIGALACTOSYL DIACYL GLYCEROL (DGDG) C₅₁ H₉₆ O₁₅ LDQFLSUQYHBXSX-HXXRYREZSA-N		Interactions Focus chain CJ [auth C] Focus chain DG [auth h] Focus chain DJ [auth C] Focus chain QD [auth B] Focus chain TJ [auth c] Focus chain UJ [auth c] Focus chain WD [auth H] Focus chain ZE [auth b] Interactions & Density Focus chain CJ [auth C] Focus chain DG [auth h] Focus chain DJ [auth C] Focus chain QD [auth B] Focus chain TJ [auth c] Focus chain UJ [auth c] Focus chain WD [auth H] Focus chain ZE [auth b]
CLA (Subject of Investigation/LOI) Query on CLA Download Ideal Coordinates CCD File SDF format, chain AC [auth 7] SDF format, chain AD [auth B] SDF format, chain AE [auth J] SDF format, chain AH [auth 8] SDF format, chain AJ [auth C] SDF format, chain AL [auth 5] SDF format, chain AM [auth G] SDF format, chain BC [auth 7] SDF format, chain BD [auth B] SDF format, chain BE [auth J] SDF format, chain BF [auth b] SDF format, chain BH [auth 8] SDF format, chain BL [auth 5] SDF format, chain BM [auth G] SDF format, chain CC [auth 7] SDF format, chain CD [auth B] SDF format, chain CE [auth J] SDF format, chain CF [auth b] SDF format, chain CH [auth 8] SDF format, chain CK [auth 3] SDF format, chain CM [auth G] SDF format, chain DC [auth 7] SDF format, chain DD [auth B] SDF format, chain DE [auth J] SDF format, chain DF [auth b] SDF format, chain DH [auth 8] SDF format, chain DK [auth 3] SDF format, chain DM [auth G] SDF format, chain EC [auth 7] SDF format, chain ED [auth B] SDF format, chain EE [auth J] SDF format, chain EF [auth b] SDF format, chain EH [auth 8] SDF format, chain EK [auth 3] SDF format, chain FD [auth B] SDF format, chain FE [auth J] SDF format, chain FF [auth b] SDF format, chain FI [auth d] SDF format, chain FJ [auth c] SDF format, chain FK [auth 3] SDF format, chain GD [auth B] SDF format, chain GF [auth b] SDF format, chain GG [auth 2] SDF format, chain GI [auth d] SDF format, chain GJ [auth c] SDF format, chain GK [auth 3] SDF format, chain HB [auth 6] SDF format, chain HD [auth B] SDF format, chain HF [auth b] SDF format, chain HG [auth 2] SDF format, chain HI [auth d] SDF format, chain HJ [auth c] SDF format, chain IB [auth 6] SDF format, chain ID [auth B] SDF format, chain IF [auth b] SDF format, chain IG [auth 2] SDF format, chain IJ [auth c] SDF format, chain JB [auth 6] SDF format, chain JF [auth b] SDF format, chain JG [auth 2] SDF format, chain JJ [auth c] SDF format, chain JK [auth 4] SDF format, chain KB [auth 6] SDF format, chain KF [auth b] SDF format, chain KG [auth 2] SDF format, chain KJ [auth c] SDF format, chain KK [auth 4] SDF format, chain KL [auth g] SDF format, chain LB [auth 6] SDF format, chain LC [auth A] SDF format, chain LF [auth b] SDF format, chain LG [auth 2] SDF format, chain LJ [auth c] SDF format, chain LK [auth 4] SDF format, chain LL [auth g] SDF format, chain MB [auth 6] SDF format, chain MC [auth A] SDF format, chain MF [auth b] SDF format, chain MJ [auth c] SDF format, chain MK [auth 4] SDF format, chain ML [auth g] SDF format, chain NB [auth 6] SDF format, chain ND [auth B] SDF format, chain NF [auth b] SDF format, chain NJ [auth c] SDF format, chain NK [auth 4] SDF format, chain NL [auth g] SDF format, chain OB [auth 6] SDF format, chain OC [auth A] SDF format, chain OF [auth b] SDF format, chain OI [auth C] SDF format, chain OJ [auth c] SDF format, chain OL [auth g] SDF format, chain PB [auth 6] SDF format, chain PF [auth b] SDF format, chain PI [auth C] SDF format, chain PJ [auth c] SDF format, chain PL [auth g] SDF format, chain QA [auth 1] SDF format, chain QI [auth C] SDF format, chain QJ [auth c] SDF format, chain QL [auth g] SDF format, chain RA [auth 1] SDF format, chain RI [auth C] SDF format, chain RJ [auth c] SDF format, chain RL [auth g] SDF format, chain SA [auth 1] SDF format, chain SE [auth a] SDF format, chain SI [auth C] SDF format, chain TA [auth 1] SDF format, chain TE [auth a] SDF format, chain TH [auth D] SDF format, chain TI [auth C] SDF format, chain UA [auth 1] SDF format, chain UC [auth B] SDF format, chain UI [auth C] SDF format, chain UK [auth 5] SDF format, chain VA [auth 1] SDF format, chain VB [auth 7] SDF format, chain VC [auth B] SDF format, chain VE [auth a] SDF format, chain VF [auth b] SDF format, chain VH [auth D] SDF format, chain VI [auth C] SDF format, chain VJ [auth 9] SDF format, chain VK [auth 5] SDF format, chain WA [auth 1] SDF format, chain WB [auth 7] SDF format, chain WC [auth B] SDF format, chain WH [auth D] SDF format, chain WI [auth C] SDF format, chain WJ [auth 9] SDF format, chain WK [auth 5] SDF format, chain XA [auth 1] SDF format, chain XB [auth 7] SDF format, chain XC [auth B] SDF format, chain XD [auth J] SDF format, chain XI [auth C] SDF format, chain XJ [auth 9] SDF format, chain XK [auth 5] SDF format, chain YA [auth 1] SDF format, chain YB [auth 7] SDF format, chain YC [auth B] SDF format, chain YD [auth J] SDF format, chain YI [auth C] SDF format, chain YJ [auth 9] SDF format, chain YK [auth 5] SDF format, chain ZA [auth 1] SDF format, chain ZB [auth 7] SDF format, chain ZC [auth B] SDF format, chain ZD [auth J] SDF format, chain ZG [auth 8] SDF format, chain ZI [auth C] SDF format, chain ZJ [auth 9] SDF format, chain ZK [auth 5] SDF format, chain ZL [auth G] MOL2 format, chain AC [auth 7] MOL2 format, chain AD [auth B] MOL2 format, chain AE [auth J] MOL2 format, chain AH [auth 8] MOL2 format, chain AJ [auth C] MOL2 format, chain AL [auth 5] MOL2 format, chain AM [auth G] MOL2 format, chain BC [auth 7] MOL2 format, chain BD [auth B] MOL2 format, chain BE [auth J] MOL2 format, chain BF [auth b] MOL2 format, chain BH [auth 8] MOL2 format, chain BL [auth 5] MOL2 format, chain BM [auth G] MOL2 format, chain CC [auth 7] MOL2 format, chain CD [auth B] MOL2 format, chain CE [auth J] MOL2 format, chain CF [auth b] MOL2 format, chain CH [auth 8] MOL2 format, chain CK [auth 3] MOL2 format, chain CM [auth G] MOL2 format, chain DC [auth 7] MOL2 format, chain DD [auth B] MOL2 format, chain DE [auth J] MOL2 format, chain DF [auth b] MOL2 format, chain DH [auth 8] MOL2 format, chain DK [auth 3] MOL2 format, chain DM [auth G] MOL2 format, chain EC [auth 7] MOL2 format, chain ED [auth B] MOL2 format, chain EE [auth J] MOL2 format, chain EF [auth b] MOL2 format, chain EH [auth 8] MOL2 format, chain EK [auth 3] MOL2 format, chain FD [auth B] MOL2 format, chain FE [auth J] MOL2 format, chain FF [auth b] MOL2 format, chain FI [auth d] MOL2 format, chain FJ [auth c] MOL2 format, chain FK [auth 3] MOL2 format, chain GD [auth B] MOL2 format, chain GF [auth b] MOL2 format, chain GG [auth 2] MOL2 format, chain GI [auth d] MOL2 format, chain GJ [auth c] MOL2 format, chain GK [auth 3] MOL2 format, chain HB [auth 6] MOL2 format, chain HD [auth B] MOL2 format, chain HF [auth b] MOL2 format, chain HG [auth 2] MOL2 format, chain HI [auth d] MOL2 format, chain HJ [auth c] MOL2 format, chain IB [auth 6] MOL2 format, chain ID [auth B] MOL2 format, chain IF [auth b] MOL2 format, chain IG [auth 2] MOL2 format, chain IJ [auth c] MOL2 format, chain JB [auth 6] MOL2 format, chain JF [auth b] MOL2 format, chain JG [auth 2] MOL2 format, chain JJ [auth c] MOL2 format, chain JK [auth 4] MOL2 format, chain KB [auth 6] MOL2 format, chain KF [auth b] MOL2 format, chain KG [auth 2] MOL2 format, chain KJ [auth c] MOL2 format, chain KK [auth 4] MOL2 format, chain KL [auth g] MOL2 format, chain LB [auth 6] MOL2 format, chain LC [auth A] MOL2 format, chain LF [auth b] MOL2 format, chain LG [auth 2] MOL2 format, chain LJ [auth c] MOL2 format, chain LK [auth 4] MOL2 format, chain LL [auth g] MOL2 format, chain MB [auth 6] MOL2 format, chain MC [auth A] MOL2 format, chain MF [auth b] MOL2 format, chain MJ [auth c] MOL2 format, chain MK [auth 4] MOL2 format, chain ML [auth g] MOL2 format, chain NB [auth 6] MOL2 format, chain ND [auth B] MOL2 format, chain NF [auth b] MOL2 format, chain NJ [auth c] MOL2 format, chain NK [auth 4] MOL2 format, chain NL [auth g] MOL2 format, chain OB [auth 6] MOL2 format, chain OC [auth A] MOL2 format, chain OF [auth b] MOL2 format, chain OI [auth C] MOL2 format, chain OJ [auth c] MOL2 format, chain OL [auth g] MOL2 format, chain PB [auth 6] MOL2 format, chain PF [auth b] MOL2 format, chain PI [auth C] MOL2 format, chain PJ [auth c] MOL2 format, chain PL [auth g] MOL2 format, chain QA [auth 1] MOL2 format, chain QI [auth C] MOL2 format, chain QJ [auth c] MOL2 format, chain QL [auth g] MOL2 format, chain RA [auth 1] MOL2 format, chain RI [auth C] MOL2 format, chain RJ [auth c] MOL2 format, chain RL [auth g] MOL2 format, chain SA [auth 1] MOL2 format, chain SE [auth a] MOL2 format, chain SI [auth C] MOL2 format, chain TA [auth 1] MOL2 format, chain TE [auth a] MOL2 format, chain TH [auth D] MOL2 format, chain TI [auth C] MOL2 format, chain UA [auth 1] MOL2 format, chain UC [auth B] MOL2 format, chain UI [auth C] MOL2 format, chain UK [auth 5] MOL2 format, chain VA [auth 1] MOL2 format, chain VB [auth 7] MOL2 format, chain VC [auth B] MOL2 format, chain VE [auth a] MOL2 format, chain VF [auth b] MOL2 format, chain VH [auth D] MOL2 format, chain VI [auth C] MOL2 format, chain VJ [auth 9] MOL2 format, chain VK [auth 5] MOL2 format, chain WA [auth 1] MOL2 format, chain WB [auth 7] MOL2 format, chain WC [auth B] MOL2 format, chain WH [auth D] MOL2 format, chain WI [auth C] MOL2 format, chain WJ [auth 9] MOL2 format, chain WK [auth 5] MOL2 format, chain XA [auth 1] MOL2 format, chain XB [auth 7] MOL2 format, chain XC [auth B] MOL2 format, chain XD [auth J] MOL2 format, chain XI [auth C] MOL2 format, chain XJ [auth 9] MOL2 format, chain XK [auth 5] MOL2 format, chain YA [auth 1] MOL2 format, chain YB [auth 7] MOL2 format, chain YC [auth B] MOL2 format, chain YD [auth J] MOL2 format, chain YI [auth C] MOL2 format, chain YJ [auth 9] MOL2 format, chain YK [auth 5] MOL2 format, chain ZA [auth 1] MOL2 format, chain ZB [auth 7] MOL2 format, chain ZC [auth B] MOL2 format, chain ZD [auth J] MOL2 format, chain ZG [auth 8] MOL2 format, chain ZI [auth C] MOL2 format, chain ZJ [auth 9] MOL2 format, chain ZK [auth 5] MOL2 format, chain ZL [auth G] mmCIF format, chain AC [auth 7] mmCIF format, chain AD [auth B] mmCIF format, chain AE [auth J] mmCIF format, chain AH [auth 8] mmCIF format, chain AJ [auth C] mmCIF format, chain AL [auth 5] mmCIF format, chain AM [auth G] mmCIF format, chain BC [auth 7] mmCIF format, chain BD [auth B] mmCIF format, chain BE [auth J] mmCIF format, chain BF [auth b] mmCIF format, chain BH [auth 8] mmCIF format, chain BL [auth 5] mmCIF format, chain BM [auth G] mmCIF format, chain CC [auth 7] mmCIF format, chain CD [auth B] mmCIF format, chain CE [auth J] mmCIF format, chain CF [auth b] mmCIF format, chain CH [auth 8] mmCIF format, chain CK [auth 3] mmCIF format, chain CM [auth G] mmCIF format, chain DC [auth 7] mmCIF format, chain DD [auth B] mmCIF format, chain DE [auth J] mmCIF format, chain DF [auth b] mmCIF format, chain DH [auth 8] mmCIF format, chain DK [auth 3] mmCIF format, chain DM [auth G] mmCIF format, chain EC [auth 7] mmCIF format, chain ED [auth B] mmCIF format, chain EE [auth J] mmCIF format, chain EF [auth b] mmCIF format, chain EH [auth 8] mmCIF format, chain EK [auth 3] mmCIF format, chain FD [auth B] mmCIF format, chain FE [auth J] mmCIF format, chain FF [auth b] mmCIF format, chain FI [auth d] mmCIF format, chain FJ [auth c] mmCIF format, chain FK [auth 3] mmCIF format, chain GD [auth B] mmCIF format, chain GF [auth b] mmCIF format, chain GG [auth 2] mmCIF format, chain GI [auth d] mmCIF format, chain GJ [auth c] mmCIF format, chain GK [auth 3] mmCIF format, chain HB [auth 6] mmCIF format, chain HD [auth B] mmCIF format, chain HF [auth b] mmCIF format, chain HG [auth 2] mmCIF format, chain HI [auth d] mmCIF format, chain HJ [auth c] mmCIF format, chain IB [auth 6] mmCIF format, chain ID [auth B] mmCIF format, chain IF [auth b] mmCIF format, chain IG [auth 2] mmCIF format, chain IJ [auth c] mmCIF format, chain JB [auth 6] mmCIF format, chain JF [auth b] mmCIF format, chain JG [auth 2] mmCIF format, chain JJ [auth c] mmCIF format, chain JK [auth 4] mmCIF format, chain KB [auth 6] mmCIF format, chain KF [auth b] mmCIF format, chain KG [auth 2] mmCIF format, chain KJ [auth c] mmCIF format, chain KK [auth 4] mmCIF format, chain KL [auth g] mmCIF format, chain LB [auth 6] mmCIF format, chain LC [auth A] mmCIF format, chain LF [auth b] mmCIF format, chain LG [auth 2] mmCIF format, chain LJ [auth c] mmCIF format, chain LK [auth 4] mmCIF format, chain LL [auth g] mmCIF format, chain MB [auth 6] mmCIF format, chain MC [auth A] mmCIF format, chain MF [auth b] mmCIF format, chain MJ [auth c] mmCIF format, chain MK [auth 4] mmCIF format, chain ML [auth g] mmCIF format, chain NB [auth 6] mmCIF format, chain ND [auth B] mmCIF format, chain NF [auth b] mmCIF format, chain NJ [auth c] mmCIF format, chain NK [auth 4] mmCIF format, chain NL [auth g] mmCIF format, chain OB [auth 6] mmCIF format, chain OC [auth A] mmCIF format, chain OF [auth b] mmCIF format, chain OI [auth C] mmCIF format, chain OJ [auth c] mmCIF format, chain OL [auth g] mmCIF format, chain PB [auth 6] mmCIF format, chain PF [auth b] mmCIF format, chain PI [auth C] mmCIF format, chain PJ [auth c] mmCIF format, chain PL [auth g] mmCIF format, chain QA [auth 1] mmCIF format, chain QI [auth C] mmCIF format, chain QJ [auth c] mmCIF format, chain QL [auth g] mmCIF format, chain RA [auth 1] mmCIF format, chain RI [auth C] mmCIF format, chain RJ [auth c] mmCIF format, chain RL [auth g] mmCIF format, chain SA [auth 1] mmCIF format, chain SE [auth a] mmCIF format, chain SI [auth C] mmCIF format, chain TA [auth 1] mmCIF format, chain TE [auth a] mmCIF format, chain TH [auth D] mmCIF format, chain TI [auth C] mmCIF format, chain UA [auth 1] mmCIF format, chain UC [auth B] mmCIF format, chain UI [auth C] mmCIF format, chain UK [auth 5] mmCIF format, chain VA [auth 1] mmCIF format, chain VB [auth 7] mmCIF format, chain VC [auth B] mmCIF format, chain VE [auth a] mmCIF format, chain VF [auth b] mmCIF format, chain VH [auth D] mmCIF format, chain VI [auth C] mmCIF format, chain VJ [auth 9] mmCIF format, chain VK [auth 5] mmCIF format, chain WA [auth 1] mmCIF format, chain WB [auth 7] mmCIF format, chain WC [auth B] mmCIF format, chain WH [auth D] mmCIF format, chain WI [auth C] mmCIF format, chain WJ [auth 9] mmCIF format, chain WK [auth 5] mmCIF format, chain XA [auth 1] mmCIF format, chain XB [auth 7] mmCIF format, chain XC [auth B] mmCIF format, chain XD [auth J] mmCIF format, chain XI [auth C] mmCIF format, chain XJ [auth 9] mmCIF format, chain XK [auth 5] mmCIF format, chain YA [auth 1] mmCIF format, chain YB [auth 7] mmCIF format, chain YC [auth B] mmCIF format, chain YD [auth J] mmCIF format, chain YI [auth C] mmCIF format, chain YJ [auth 9] mmCIF format, chain YK [auth 5] mmCIF format, chain ZA [auth 1] mmCIF format, chain ZB [auth 7] mmCIF format, chain ZC [auth B] mmCIF format, chain ZD [auth J] mmCIF format, chain ZG [auth 8] mmCIF format, chain ZI [auth C] mmCIF format, chain ZJ [auth 9] mmCIF format, chain ZK [auth 5] mmCIF format, chain ZL [auth G]	AC [auth 7] AD [auth B] AE [auth J] AH [auth 8] AJ [auth C] AC [auth 7], AD [auth B], AE [auth J], AH [auth 8], AJ [auth C], AL [auth 5], AM [auth G], BC [auth 7], BD [auth B], BE [auth J], BF [auth b], BH [auth 8], BL [auth 5], BM [auth G], CC [auth 7], CD [auth B], CE [auth J], CF [auth b], CH [auth 8], CK [auth 3], CM [auth G], DC [auth 7], DD [auth B], DE [auth J], DF [auth b], DH [auth 8], DK [auth 3], DM [auth G], EC [auth 7], ED [auth B], EE [auth J], EF [auth b], EH [auth 8], EK [auth 3], FD [auth B], FE [auth J], FF [auth b], FI [auth d], FJ [auth c], FK [auth 3], GD [auth B], GF [auth b], GG [auth 2], GI [auth d], GJ [auth c], GK [auth 3], HB [auth 6], HD [auth B], HF [auth b], HG [auth 2], HI [auth d], HJ [auth c], IB [auth 6], ID [auth B], IF [auth b], IG [auth 2], IJ [auth c], JB [auth 6], JF [auth b], JG [auth 2], JJ [auth c], JK [auth 4], KB [auth 6], KF [auth b], KG [auth 2], KJ [auth c], KK [auth 4], KL [auth g], LB [auth 6], LC [auth A], LF [auth b], LG [auth 2], LJ [auth c], LK [auth 4], LL [auth g], MB [auth 6], MC [auth A], MF [auth b], MJ [auth c], MK [auth 4], ML [auth g], NB [auth 6], ND [auth B], NF [auth b], NJ [auth c], NK [auth 4], NL [auth g], OB [auth 6], OC [auth A], OF [auth b], OI [auth C], OJ [auth c], OL [auth g], PB [auth 6], PF [auth b], PI [auth C], PJ [auth c], PL [auth g], QA [auth 1], QI [auth C], QJ [auth c], QL [auth g], RA [auth 1], RI [auth C], RJ [auth c], RL [auth g], SA [auth 1], SE [auth a], SI [auth C], TA [auth 1], TE [auth a], TH [auth D], TI [auth C], UA [auth 1], UC [auth B], UI [auth C], UK [auth 5], VA [auth 1], VB [auth 7], VC [auth B], VE [auth a], VF [auth b], VH [auth D], VI [auth C], VJ [auth 9], VK [auth 5], WA [auth 1], WB [auth 7], WC [auth B], WH [auth D], WI [auth C], WJ [auth 9], WK [auth 5], XA [auth 1], XB [auth 7], XC [auth B], XD [auth J], XI [auth C], XJ [auth 9], XK [auth 5], YA [auth 1], YB [auth 7], YC [auth B], YD [auth J], YI [auth C], YJ [auth 9], YK [auth 5], ZA [auth 1], ZB [auth 7], ZC [auth B], ZD [auth J], ZG [auth 8], ZI [auth C], ZJ [auth 9], ZK [auth 5], ZL [auth G]	CHLOROPHYLL A C₅₅ H₇₂ Mg N₄ O₅ ATNHDLDRLWWWCB-AENOIHSZSA-M		Interactions Focus chain AC [auth 7] Focus chain AD [auth B] Focus chain AE [auth J] Focus chain AH [auth 8] Focus chain AJ [auth C] Focus chain AL [auth 5] Focus chain AM [auth G] Focus chain BC [auth 7] Focus chain BD [auth B] Focus chain BE [auth J] Focus chain BF [auth b] Focus chain BH [auth 8] Focus chain BL [auth 5] Focus chain BM [auth G] Focus chain CC [auth 7] Focus chain CD [auth B] Focus chain CE [auth J] Focus chain CF [auth b] Focus chain CH [auth 8] Focus chain CK [auth 3] Focus chain CM [auth G] Focus chain DC [auth 7] Focus chain DD [auth B] Focus chain DE [auth J] Focus chain DF [auth b] Focus chain DH [auth 8] Focus chain DK [auth 3] Focus chain DM [auth G] Focus chain EC [auth 7] Focus chain ED [auth B] Focus chain EE [auth J] Focus chain EF [auth b] Focus chain EH [auth 8] Focus chain EK [auth 3] Focus chain FD [auth B] Focus chain FE [auth J] Focus chain FF [auth b] Focus chain FI [auth d] Focus chain FJ [auth c] Focus chain FK [auth 3] Focus chain GD [auth B] Focus chain GF [auth b] Focus chain GG [auth 2] Focus chain GI [auth d] Focus chain GJ [auth c] Focus chain GK [auth 3] Focus chain HB [auth 6] Focus chain HD [auth B] Focus chain HF [auth b] Focus chain HG [auth 2] Focus chain HI [auth d] Focus chain HJ [auth c] Focus chain IB [auth 6] Focus chain ID [auth B] Focus chain IF [auth b] Focus chain IG [auth 2] Focus chain IJ [auth c] Focus chain JB [auth 6] Focus chain JF [auth b] Focus chain JG [auth 2] Focus chain JJ [auth c] Focus chain JK [auth 4] Focus chain KB [auth 6] Focus chain KF [auth b] Focus chain KG [auth 2] Focus chain KJ [auth c] Focus chain KK [auth 4] Focus chain KL [auth g] Focus chain LB [auth 6] Focus chain LC [auth A] Focus chain LF [auth b] Focus chain LG [auth 2] Focus chain LJ [auth c] Focus chain LK [auth 4] Focus chain LL [auth g] Focus chain MB [auth 6] Focus chain MC [auth A] Focus chain MF [auth b] Focus chain MJ [auth c] Focus chain MK [auth 4] Focus chain ML [auth g] Focus chain NB [auth 6] Focus chain ND [auth B] Focus chain NF [auth b] Focus chain NJ [auth c] Focus chain NK [auth 4] Focus chain NL [auth g] Focus chain OB [auth 6] Focus chain OC [auth A] Focus chain OF [auth b] Focus chain OI [auth C] Focus chain OJ [auth c] Focus chain OL [auth g] Focus chain PB [auth 6] Focus chain PF [auth b] Focus chain PI [auth C] Focus chain PJ [auth c] Focus chain PL [auth g] Focus chain QA [auth 1] Focus chain QI [auth C] Focus chain QJ [auth c] Focus chain QL [auth g] Focus chain RA [auth 1] Focus chain RI [auth C] Focus chain RJ [auth c] Focus chain RL [auth g] Focus chain SA [auth 1] Focus chain SE [auth a] Focus chain SI [auth C] Focus chain TA [auth 1] Focus chain TE [auth a] Focus chain TH [auth D] Focus chain TI [auth C] Focus chain UA [auth 1] Focus chain UC [auth B] Focus chain UI [auth C] Focus chain UK [auth 5] Focus chain VA [auth 1] Focus chain VB [auth 7] Focus chain VC [auth B] Focus chain VE [auth a] Focus chain VF [auth b] Focus chain VH [auth D] Focus chain VI [auth C] Focus chain VJ [auth 9] Focus chain VK [auth 5] Focus chain WA [auth 1] Focus chain WB [auth 7] Focus chain WC [auth B] Focus chain WH [auth D] Focus chain WI [auth C] Focus chain WJ [auth 9] Focus chain WK [auth 5] Focus chain XA [auth 1] Focus chain XB [auth 7] Focus chain XC [auth B] Focus chain XD [auth J] Focus chain XI [auth C] Focus chain XJ [auth 9] Focus chain XK [auth 5] Focus chain YA [auth 1] Focus chain YB [auth 7] Focus chain YC [auth B] Focus chain YD [auth J] Focus chain YI [auth C] Focus chain YJ [auth 9] Focus chain YK [auth 5] Focus chain ZA [auth 1] Focus chain ZB [auth 7] Focus chain ZC [auth B] Focus chain ZD [auth J] Focus chain ZG [auth 8] Focus chain ZI [auth C] Focus chain ZJ [auth 9] Focus chain ZK [auth 5] Focus chain ZL [auth G] Interactions & Density Focus chain AC [auth 7] Focus chain AD [auth B] Focus chain AE [auth J] Focus chain AH [auth 8] Focus chain AJ [auth C] Focus chain AL [auth 5] Focus chain AM [auth G] Focus chain BC [auth 7] Focus chain BD [auth B] Focus chain BE [auth J] Focus chain BF [auth b] Focus chain BH [auth 8] Focus chain BL [auth 5] Focus chain BM [auth G] Focus chain CC [auth 7] Focus chain CD [auth B] Focus chain CE [auth J] Focus chain CF [auth b] Focus chain CH [auth 8] Focus chain CK [auth 3] Focus chain CM [auth G] Focus chain DC [auth 7] Focus chain DD [auth B] Focus chain DE [auth J] Focus chain DF [auth b] Focus chain DH [auth 8] Focus chain DK [auth 3] Focus chain DM [auth G] Focus chain EC [auth 7] Focus chain ED [auth B] Focus chain EE [auth J] Focus chain EF [auth b] Focus chain EH [auth 8] Focus chain EK [auth 3] Focus chain FD [auth B] Focus chain FE [auth J] Focus chain FF [auth b] Focus chain FI [auth d] Focus chain FJ [auth c] Focus chain FK [auth 3] Focus chain GD [auth B] Focus chain GF [auth b] Focus chain GG [auth 2] Focus chain GI [auth d] Focus chain GJ [auth c] Focus chain GK [auth 3] Focus chain HB [auth 6] Focus chain HD [auth B] Focus chain HF [auth b] Focus chain HG [auth 2] Focus chain HI [auth d] Focus chain HJ [auth c] Focus chain IB [auth 6] Focus chain ID [auth B] Focus chain IF [auth b] Focus chain IG [auth 2] Focus chain IJ [auth c] Focus chain JB [auth 6] Focus chain JF [auth b] Focus chain JG [auth 2] Focus chain JJ [auth c] Focus chain JK [auth 4] Focus chain KB [auth 6] Focus chain KF [auth b] Focus chain KG [auth 2] Focus chain KJ [auth c] Focus chain KK [auth 4] Focus chain KL [auth g] Focus chain LB [auth 6] Focus chain LC [auth A] Focus chain LF [auth b] Focus chain LG [auth 2] Focus chain LJ [auth c] Focus chain LK [auth 4] Focus chain LL [auth g] Focus chain MB [auth 6] Focus chain MC [auth A] Focus chain MF [auth b] Focus chain MJ [auth c] Focus chain MK [auth 4] Focus chain ML [auth g] Focus chain NB [auth 6] Focus chain ND [auth B] Focus chain NF [auth b] Focus chain NJ [auth c] Focus chain NK [auth 4] Focus chain NL [auth g] Focus chain OB [auth 6] Focus chain OC [auth A] Focus chain OF [auth b] Focus chain OI [auth C] Focus chain OJ [auth c] Focus chain OL [auth g] Focus chain PB [auth 6] Focus chain PF [auth b] Focus chain PI [auth C] Focus chain PJ [auth c] Focus chain PL [auth g] Focus chain QA [auth 1] Focus chain QI [auth C] Focus chain QJ [auth c] Focus chain QL [auth g] Focus chain RA [auth 1] Focus chain RI [auth C] Focus chain RJ [auth c] Focus chain RL [auth g] Focus chain SA [auth 1] Focus chain SE [auth a] Focus chain SI [auth C] Focus chain TA [auth 1] Focus chain TE [auth a] Focus chain TH [auth D] Focus chain TI [auth C] Focus chain UA [auth 1] Focus chain UC [auth B] Focus chain UI [auth C] Focus chain UK [auth 5] Focus chain VA [auth 1] Focus chain VB [auth 7] Focus chain VC [auth B] Focus chain VE [auth a] Focus chain VF [auth b] Focus chain VH [auth D] Focus chain VI [auth C] Focus chain VJ [auth 9] Focus chain VK [auth 5] Focus chain WA [auth 1] Focus chain WB [auth 7] Focus chain WC [auth B] Focus chain WH [auth D] Focus chain WI [auth C] Focus chain WJ [auth 9] Focus chain WK [auth 5] Focus chain XA [auth 1] Focus chain XB [auth 7] Focus chain XC [auth B] Focus chain XD [auth J] Focus chain XI [auth C] Focus chain XJ [auth 9] Focus chain XK [auth 5] Focus chain YA [auth 1] Focus chain YB [auth 7] Focus chain YC [auth B] Focus chain YD [auth J] Focus chain YI [auth C] Focus chain YJ [auth 9] Focus chain YK [auth 5] Focus chain ZA [auth 1] Focus chain ZB [auth 7] Focus chain ZC [auth B] Focus chain ZD [auth J] Focus chain ZG [auth 8] Focus chain ZI [auth C] Focus chain ZJ [auth 9] Focus chain ZK [auth 5] Focus chain ZL [auth G]
PHO (Subject of Investigation/LOI) Query on PHO Download Ideal Coordinates CCD File SDF format, chain EI [auth d] SDF format, chain NC [auth A] SDF format, chain QH [auth D] SDF format, chain UE [auth a] MOL2 format, chain EI [auth d] MOL2 format, chain NC [auth A] MOL2 format, chain QH [auth D] MOL2 format, chain UE [auth a] mmCIF format, chain EI [auth d] mmCIF format, chain NC [auth A] mmCIF format, chain QH [auth D] mmCIF format, chain UE [auth a]	EI [auth d], NC [auth A], QH [auth D], UE [auth a]	PHEOPHYTIN A C₅₅ H₇₄ N₄ O₅ CQIKWXUXPNUNDV-RCBXBCQGSA-N		Interactions Focus chain EI [auth d] Focus chain NC [auth A] Focus chain QH [auth D] Focus chain UE [auth a] Interactions & Density Focus chain EI [auth d] Focus chain NC [auth A] Focus chain QH [auth D] Focus chain UE [auth a]
SQD (Subject of Investigation/LOI) Query on SQD Download Ideal Coordinates CCD File SDF format, chain AF [auth b] SDF format, chain NI [auth C] SDF format, chain QE [auth X] SDF format, chain RD [auth B] SDF format, chain SD [auth B] MOL2 format, chain AF [auth b] MOL2 format, chain NI [auth C] MOL2 format, chain QE [auth X] MOL2 format, chain RD [auth B] MOL2 format, chain SD [auth B] mmCIF format, chain AF [auth b] mmCIF format, chain NI [auth C] mmCIF format, chain QE [auth X] mmCIF format, chain RD [auth B] mmCIF format, chain SD [auth B]	AF [auth b], NI [auth C], QE [auth X], RD [auth B], SD [auth B]	1,2-DI-O-ACYL-3-O-[6-DEOXY-6-SULFO-ALPHA-D-GLUCOPYRANOSYL]-SN-GLYCEROL C₄₁ H₇₈ O₁₂ S RVUUQPKXGDTQPG-JUDHQOGESA-N		Interactions Focus chain AF [auth b] Focus chain NI [auth C] Focus chain QE [auth X] Focus chain RD [auth B] Focus chain SD [auth B] Interactions & Density Focus chain AF [auth b] Focus chain NI [auth C] Focus chain QE [auth X] Focus chain RD [auth B] Focus chain SD [auth B]
LMG (Subject of Investigation/LOI) Query on LMG Download Ideal Coordinates CCD File SDF format, chain AG [auth f] SDF format, chain AI [auth D] SDF format, chain LD [auth B] SDF format, chain LE [auth L] SDF format, chain MD [auth B] SDF format, chain NE [auth M] SDF format, chain OD [auth B] SDF format, chain OE [auth N] SDF format, chain OH [auth 8] SDF format, chain PD [auth B] SDF format, chain RC [auth A] SDF format, chain SF [auth b] SDF format, chain TD [auth B] SDF format, chain TF [auth b] SDF format, chain UF [auth b] SDF format, chain WF [auth b] SDF format, chain XE [auth a] SDF format, chain XF [auth b] SDF format, chain XG [auth 2] SDF format, chain YF [auth b] SDF format, chain YG [auth 8] MOL2 format, chain AG [auth f] MOL2 format, chain AI [auth D] MOL2 format, chain LD [auth B] MOL2 format, chain LE [auth L] MOL2 format, chain MD [auth B] MOL2 format, chain NE [auth M] MOL2 format, chain OD [auth B] MOL2 format, chain OE [auth N] MOL2 format, chain OH [auth 8] MOL2 format, chain PD [auth B] MOL2 format, chain RC [auth A] MOL2 format, chain SF [auth b] MOL2 format, chain TD [auth B] MOL2 format, chain TF [auth b] MOL2 format, chain UF [auth b] MOL2 format, chain WF [auth b] MOL2 format, chain XE [auth a] MOL2 format, chain XF [auth b] MOL2 format, chain XG [auth 2] MOL2 format, chain YF [auth b] MOL2 format, chain YG [auth 8] mmCIF format, chain AG [auth f] mmCIF format, chain AI [auth D] mmCIF format, chain LD [auth B] mmCIF format, chain LE [auth L] mmCIF format, chain MD [auth B] mmCIF format, chain NE [auth M] mmCIF format, chain OD [auth B] mmCIF format, chain OE [auth N] mmCIF format, chain OH [auth 8] mmCIF format, chain PD [auth B] mmCIF format, chain RC [auth A] mmCIF format, chain SF [auth b] mmCIF format, chain TD [auth B] mmCIF format, chain TF [auth b] mmCIF format, chain UF [auth b] mmCIF format, chain WF [auth b] mmCIF format, chain XE [auth a] mmCIF format, chain XF [auth b] mmCIF format, chain XG [auth 2] mmCIF format, chain YF [auth b] mmCIF format, chain YG [auth 8]	AG [auth f] AI [auth D] LD [auth B] LE [auth L] MD [auth B] AG [auth f], AI [auth D], LD [auth B], LE [auth L], MD [auth B], NE [auth M], OD [auth B], OE [auth N], OH [auth 8], PD [auth B], RC [auth A], SF [auth b], TD [auth B], TF [auth b], UF [auth b], WF [auth b], XE [auth a], XF [auth b], XG [auth 2], YF [auth b], YG [auth 8]	1,2-DISTEAROYL-MONOGALACTOSYL-DIGLYCERIDE C₄₅ H₈₆ O₁₀ DCLTVZLYPPIIID-CVELTQQQSA-N		Interactions Focus chain AG [auth f] Focus chain AI [auth D] Focus chain LD [auth B] Focus chain LE [auth L] Focus chain MD [auth B] Focus chain NE [auth M] Focus chain OD [auth B] Focus chain OE [auth N] Focus chain OH [auth 8] Focus chain PD [auth B] Focus chain RC [auth A] Focus chain SF [auth b] Focus chain TD [auth B] Focus chain TF [auth b] Focus chain UF [auth b] Focus chain WF [auth b] Focus chain XE [auth a] Focus chain XF [auth b] Focus chain XG [auth 2] Focus chain YF [auth b] Focus chain YG [auth 8] Interactions & Density Focus chain AG [auth f] Focus chain AI [auth D] Focus chain LD [auth B] Focus chain LE [auth L] Focus chain MD [auth B] Focus chain NE [auth M] Focus chain OD [auth B] Focus chain OE [auth N] Focus chain OH [auth 8] Focus chain PD [auth B] Focus chain RC [auth A] Focus chain SF [auth b] Focus chain TD [auth B] Focus chain TF [auth b] Focus chain UF [auth b] Focus chain WF [auth b] Focus chain XE [auth a] Focus chain XF [auth b] Focus chain XG [auth 2] Focus chain YF [auth b] Focus chain YG [auth 8]
PL9 (Subject of Investigation/LOI) Query on PL9 Download Ideal Coordinates CCD File SDF format, chain JI [auth d] SDF format, chain YH [auth D] MOL2 format, chain JI [auth d] MOL2 format, chain YH [auth D] mmCIF format, chain JI [auth d] mmCIF format, chain YH [auth D]	JI [auth d], YH [auth D]	2,3-DIMETHYL-5-(3,7,11,15,19,23,27,31,35-NONAMETHYL-2,6,10,14,18,22,26,30,34-HEXATRIACONTANONAENYL-2,5-CYCLOHEXADIENE-1,4-DIONE-2,3-DIMETHYL-5-SOLANESYL-1,4-BENZOQUINONE C₅₃ H₈₀ O₂ FKUYMLZIRPABFK-UHFFFAOYSA-N		Interactions Focus chain JI [auth d] Focus chain YH [auth D] Interactions & Density Focus chain JI [auth d] Focus chain YH [auth D]
LHG (Subject of Investigation/LOI) Query on LHG Download Ideal Coordinates CCD File SDF format, chain DI [auth d] SDF format, chain EG [auth l] SDF format, chain KI [auth d] SDF format, chain QC [auth A] SDF format, chain RE [auth a] SDF format, chain SH [auth D] SDF format, chain TC [auth B] SDF format, chain ZH [auth D] MOL2 format, chain DI [auth d] MOL2 format, chain EG [auth l] MOL2 format, chain KI [auth d] MOL2 format, chain QC [auth A] MOL2 format, chain RE [auth a] MOL2 format, chain SH [auth D] MOL2 format, chain TC [auth B] MOL2 format, chain ZH [auth D] mmCIF format, chain DI [auth d] mmCIF format, chain EG [auth l] mmCIF format, chain KI [auth d] mmCIF format, chain QC [auth A] mmCIF format, chain RE [auth a] mmCIF format, chain SH [auth D] mmCIF format, chain TC [auth B] mmCIF format, chain ZH [auth D]	DI [auth d] EG [auth l] KI [auth d] QC [auth A] RE [auth a] DI [auth d], EG [auth l], KI [auth d], QC [auth A], RE [auth a], SH [auth D], TC [auth B], ZH [auth D]	1,2-DIPALMITOYL-PHOSPHATIDYL-GLYCEROLE C₃₈ H₇₅ O₁₀ P BIABMEZBCHDPBV-MPQUPPDSSA-N		Interactions Focus chain DI [auth d] Focus chain EG [auth l] Focus chain KI [auth d] Focus chain QC [auth A] Focus chain RE [auth a] Focus chain SH [auth D] Focus chain TC [auth B] Focus chain ZH [auth D] Interactions & Density Focus chain DI [auth d] Focus chain EG [auth l] Focus chain KI [auth d] Focus chain QC [auth A] Focus chain RE [auth a] Focus chain SH [auth D] Focus chain TC [auth B] Focus chain ZH [auth D]
A86 (Subject of Investigation/LOI) Query on A86 Download Ideal Coordinates CCD File SDF format, chain BB [auth 1] SDF format, chain CB [auth 1] SDF format, chain DB [auth 1] SDF format, chain DL [auth 5] SDF format, chain EL [auth 5] SDF format, chain EM [auth G] SDF format, chain FH [auth 8] SDF format, chain GC [auth 7] SDF format, chain GE [auth J] SDF format, chain GH [auth 8] SDF format, chain HC [auth 7] SDF format, chain HE [auth J] SDF format, chain HH [auth 8] SDF format, chain IC [auth 7] SDF format, chain IH [auth 8] SDF format, chain JH [auth 8] SDF format, chain MG [auth 2] SDF format, chain NG [auth 2] SDF format, chain OG [auth 2] SDF format, chain OK [auth 4] SDF format, chain PE [auth W] SDF format, chain PG [auth 2] SDF format, chain QB [auth 6] SDF format, chain QG [auth 2] SDF format, chain RB [auth 6] SDF format, chain RG [auth 2] SDF format, chain TL [auth g] SDF format, chain UL [auth g] MOL2 format, chain BB [auth 1] MOL2 format, chain CB [auth 1] MOL2 format, chain DB [auth 1] MOL2 format, chain DL [auth 5] MOL2 format, chain EL [auth 5] MOL2 format, chain EM [auth G] MOL2 format, chain FH [auth 8] MOL2 format, chain GC [auth 7] MOL2 format, chain GE [auth J] MOL2 format, chain GH [auth 8] MOL2 format, chain HC [auth 7] MOL2 format, chain HE [auth J] MOL2 format, chain HH [auth 8] MOL2 format, chain IC [auth 7] MOL2 format, chain IH [auth 8] MOL2 format, chain JH [auth 8] MOL2 format, chain MG [auth 2] MOL2 format, chain NG [auth 2] MOL2 format, chain OG [auth 2] MOL2 format, chain OK [auth 4] MOL2 format, chain PE [auth W] MOL2 format, chain PG [auth 2] MOL2 format, chain QB [auth 6] MOL2 format, chain QG [auth 2] MOL2 format, chain RB [auth 6] MOL2 format, chain RG [auth 2] MOL2 format, chain TL [auth g] MOL2 format, chain UL [auth g] mmCIF format, chain BB [auth 1] mmCIF format, chain CB [auth 1] mmCIF format, chain DB [auth 1] mmCIF format, chain DL [auth 5] mmCIF format, chain EL [auth 5] mmCIF format, chain EM [auth G] mmCIF format, chain FH [auth 8] mmCIF format, chain GC [auth 7] mmCIF format, chain GE [auth J] mmCIF format, chain GH [auth 8] mmCIF format, chain HC [auth 7] mmCIF format, chain HE [auth J] mmCIF format, chain HH [auth 8] mmCIF format, chain IC [auth 7] mmCIF format, chain IH [auth 8] mmCIF format, chain JH [auth 8] mmCIF format, chain MG [auth 2] mmCIF format, chain NG [auth 2] mmCIF format, chain OG [auth 2] mmCIF format, chain OK [auth 4] mmCIF format, chain PE [auth W] mmCIF format, chain PG [auth 2] mmCIF format, chain QB [auth 6] mmCIF format, chain QG [auth 2] mmCIF format, chain RB [auth 6] mmCIF format, chain RG [auth 2] mmCIF format, chain TL [auth g] mmCIF format, chain UL [auth g]	BB [auth 1] CB [auth 1] DB [auth 1] DL [auth 5] EL [auth 5] BB [auth 1], CB [auth 1], DB [auth 1], DL [auth 5], EL [auth 5], EM [auth G], FH [auth 8], GC [auth 7], GE [auth J], GH [auth 8], HC [auth 7], HE [auth J], HH [auth 8], IC [auth 7], IH [auth 8], JH [auth 8], MG [auth 2], NG [auth 2], OG [auth 2], OK [auth 4], PE [auth W], PG [auth 2], QB [auth 6], QG [auth 2], RB [auth 6], RG [auth 2], TL [auth g], UL [auth g]	(3S,3'S,5R,5'R,6S,6'R,8'R)-3,5'-dihydroxy-8-oxo-6',7'-didehydro-5,5',6,6',7,8-hexahydro-5,6-epoxy-beta,beta-caroten-3'- yl acetate C₄₂ H₅₈ O₆ SJWWTRQNNRNTPU-XJUZQKKNSA-N		Interactions Focus chain BB [auth 1] Focus chain CB [auth 1] Focus chain DB [auth 1] Focus chain DL [auth 5] Focus chain EL [auth 5] Focus chain EM [auth G] Focus chain FH [auth 8] Focus chain GC [auth 7] Focus chain GE [auth J] Focus chain GH [auth 8] Focus chain HC [auth 7] Focus chain HE [auth J] Focus chain HH [auth 8] Focus chain IC [auth 7] Focus chain IH [auth 8] Focus chain JH [auth 8] Focus chain MG [auth 2] Focus chain NG [auth 2] Focus chain OG [auth 2] Focus chain OK [auth 4] Focus chain PE [auth W] Focus chain PG [auth 2] Focus chain QB [auth 6] Focus chain QG [auth 2] Focus chain RB [auth 6] Focus chain RG [auth 2] Focus chain TL [auth g] Focus chain UL [auth g] Interactions & Density Focus chain BB [auth 1] Focus chain CB [auth 1] Focus chain DB [auth 1] Focus chain DL [auth 5] Focus chain EL [auth 5] Focus chain EM [auth G] Focus chain FH [auth 8] Focus chain GC [auth 7] Focus chain GE [auth J] Focus chain GH [auth 8] Focus chain HC [auth 7] Focus chain HE [auth J] Focus chain HH [auth 8] Focus chain IC [auth 7] Focus chain IH [auth 8] Focus chain JH [auth 8] Focus chain MG [auth 2] Focus chain NG [auth 2] Focus chain OG [auth 2] Focus chain OK [auth 4] Focus chain PE [auth W] Focus chain PG [auth 2] Focus chain QB [auth 6] Focus chain QG [auth 2] Focus chain RB [auth 6] Focus chain RG [auth 2] Focus chain TL [auth g] Focus chain UL [auth g]
HEM (Subject of Investigation/LOI) Query on HEM Download Ideal Coordinates CCD File SDF format, chain UD [auth E] SDF format, chain ZF [auth f] MOL2 format, chain UD [auth E] MOL2 format, chain ZF [auth f] mmCIF format, chain UD [auth E] mmCIF format, chain ZF [auth f]	UD [auth E], ZF [auth f]	PROTOPORPHYRIN IX CONTAINING FE C₃₄ H₃₂ Fe N₄ O₄ KABFMIBPWCXCRK-RGGAHWMASA-L		Interactions Focus chain UD [auth E] Focus chain ZF [auth f] Interactions & Density Focus chain UD [auth E] Focus chain ZF [auth f]
KC1 (Subject of Investigation/LOI) Query on KC1 Download Ideal Coordinates CCD File SDF format, chain AK [auth 9] SDF format, chain BK [auth 9] SDF format, chain EB [auth 1] SDF format, chain FB [auth 1] SDF format, chain FL [auth 5] SDF format, chain FM [auth G] SDF format, chain GL [auth 5] SDF format, chain GM [auth G] SDF format, chain HK [auth 3] SDF format, chain HL [auth 5] SDF format, chain HM [auth G] SDF format, chain IE [auth J] SDF format, chain IK [auth 3] SDF format, chain IM [auth G] SDF format, chain JC [auth 7] SDF format, chain JE [auth J] SDF format, chain KC [auth 7] SDF format, chain KE [auth J] SDF format, chain KH [auth 8] SDF format, chain LH [auth 8] SDF format, chain MH [auth 8] SDF format, chain NH [auth 8] SDF format, chain PK [auth 4] SDF format, chain QK [auth 4] SDF format, chain RK [auth 4] SDF format, chain SB [auth 6] SDF format, chain SG [auth 2] SDF format, chain SK [auth 4] SDF format, chain TB [auth 6] SDF format, chain TG [auth 2] SDF format, chain UB [auth 6] SDF format, chain UG [auth 2] SDF format, chain VG [auth 2] SDF format, chain VL [auth g] SDF format, chain WL [auth g] SDF format, chain XL [auth g] MOL2 format, chain AK [auth 9] MOL2 format, chain BK [auth 9] MOL2 format, chain EB [auth 1] MOL2 format, chain FB [auth 1] MOL2 format, chain FL [auth 5] MOL2 format, chain FM [auth G] MOL2 format, chain GL [auth 5] MOL2 format, chain GM [auth G] MOL2 format, chain HK [auth 3] MOL2 format, chain HL [auth 5] MOL2 format, chain HM [auth G] MOL2 format, chain IE [auth J] MOL2 format, chain IK [auth 3] MOL2 format, chain IM [auth G] MOL2 format, chain JC [auth 7] MOL2 format, chain JE [auth J] MOL2 format, chain KC [auth 7] MOL2 format, chain KE [auth J] MOL2 format, chain KH [auth 8] MOL2 format, chain LH [auth 8] MOL2 format, chain MH [auth 8] MOL2 format, chain NH [auth 8] MOL2 format, chain PK [auth 4] MOL2 format, chain QK [auth 4] MOL2 format, chain RK [auth 4] MOL2 format, chain SB [auth 6] MOL2 format, chain SG [auth 2] MOL2 format, chain SK [auth 4] MOL2 format, chain TB [auth 6] MOL2 format, chain TG [auth 2] MOL2 format, chain UB [auth 6] MOL2 format, chain UG [auth 2] MOL2 format, chain VG [auth 2] MOL2 format, chain VL [auth g] MOL2 format, chain WL [auth g] MOL2 format, chain XL [auth g] mmCIF format, chain AK [auth 9] mmCIF format, chain BK [auth 9] mmCIF format, chain EB [auth 1] mmCIF format, chain FB [auth 1] mmCIF format, chain FL [auth 5] mmCIF format, chain FM [auth G] mmCIF format, chain GL [auth 5] mmCIF format, chain GM [auth G] mmCIF format, chain HK [auth 3] mmCIF format, chain HL [auth 5] mmCIF format, chain HM [auth G] mmCIF format, chain IE [auth J] mmCIF format, chain IK [auth 3] mmCIF format, chain IM [auth G] mmCIF format, chain JC [auth 7] mmCIF format, chain JE [auth J] mmCIF format, chain KC [auth 7] mmCIF format, chain KE [auth J] mmCIF format, chain KH [auth 8] mmCIF format, chain LH [auth 8] mmCIF format, chain MH [auth 8] mmCIF format, chain NH [auth 8] mmCIF format, chain PK [auth 4] mmCIF format, chain QK [auth 4] mmCIF format, chain RK [auth 4] mmCIF format, chain SB [auth 6] mmCIF format, chain SG [auth 2] mmCIF format, chain SK [auth 4] mmCIF format, chain TB [auth 6] mmCIF format, chain TG [auth 2] mmCIF format, chain UB [auth 6] mmCIF format, chain UG [auth 2] mmCIF format, chain VG [auth 2] mmCIF format, chain VL [auth g] mmCIF format, chain WL [auth g] mmCIF format, chain XL [auth g]	AK [auth 9] BK [auth 9] EB [auth 1] FB [auth 1] FL [auth 5] AK [auth 9], BK [auth 9], EB [auth 1], FB [auth 1], FL [auth 5], FM [auth G], GL [auth 5], GM [auth G], HK [auth 3], HL [auth 5], HM [auth G], IE [auth J], IK [auth 3], IM [auth G], JC [auth 7], JE [auth J], KC [auth 7], KE [auth J], KH [auth 8], LH [auth 8], MH [auth 8], NH [auth 8], PK [auth 4], QK [auth 4], RK [auth 4], SB [auth 6], SG [auth 2], SK [auth 4], TB [auth 6], TG [auth 2], UB [auth 6], UG [auth 2], VG [auth 2], VL [auth g], WL [auth g], XL [auth g]	Chlorophyll c1 C₃₅ H₃₀ Mg N₄ O₅ DGNIJJSSARBJSH-QIEHNWLWSA-L		Interactions Focus chain AK [auth 9] Focus chain BK [auth 9] Focus chain EB [auth 1] Focus chain FB [auth 1] Focus chain FL [auth 5] Focus chain FM [auth G] Focus chain GL [auth 5] Focus chain GM [auth G] Focus chain HK [auth 3] Focus chain HL [auth 5] Focus chain HM [auth G] Focus chain IE [auth J] Focus chain IK [auth 3] Focus chain IM [auth G] Focus chain JC [auth 7] Focus chain JE [auth J] Focus chain KC [auth 7] Focus chain KE [auth J] Focus chain KH [auth 8] Focus chain LH [auth 8] Focus chain MH [auth 8] Focus chain NH [auth 8] Focus chain PK [auth 4] Focus chain QK [auth 4] Focus chain RK [auth 4] Focus chain SB [auth 6] Focus chain SG [auth 2] Focus chain SK [auth 4] Focus chain TB [auth 6] Focus chain TG [auth 2] Focus chain UB [auth 6] Focus chain UG [auth 2] Focus chain VG [auth 2] Focus chain VL [auth g] Focus chain WL [auth g] Focus chain XL [auth g] Interactions & Density Focus chain AK [auth 9] Focus chain BK [auth 9] Focus chain EB [auth 1] Focus chain FB [auth 1] Focus chain FL [auth 5] Focus chain FM [auth G] Focus chain GL [auth 5] Focus chain GM [auth G] Focus chain HK [auth 3] Focus chain HL [auth 5] Focus chain HM [auth G] Focus chain IE [auth J] Focus chain IK [auth 3] Focus chain IM [auth G] Focus chain JC [auth 7] Focus chain JE [auth J] Focus chain KC [auth 7] Focus chain KE [auth J] Focus chain KH [auth 8] Focus chain LH [auth 8] Focus chain MH [auth 8] Focus chain NH [auth 8] Focus chain PK [auth 4] Focus chain QK [auth 4] Focus chain RK [auth 4] Focus chain SB [auth 6] Focus chain SG [auth 2] Focus chain SK [auth 4] Focus chain TB [auth 6] Focus chain TG [auth 2] Focus chain UB [auth 6] Focus chain UG [auth 2] Focus chain VG [auth 2] Focus chain VL [auth g] Focus chain WL [auth g] Focus chain XL [auth g]
DD6 (Subject of Investigation/LOI) Query on DD6 Download Ideal Coordinates CCD File SDF format, chain AB [auth 1] SDF format, chain CL [auth 5] SDF format, chain FC [auth 7] SDF format, chain SL [auth g] MOL2 format, chain AB [auth 1] MOL2 format, chain CL [auth 5] MOL2 format, chain FC [auth 7] MOL2 format, chain SL [auth g] mmCIF format, chain AB [auth 1] mmCIF format, chain CL [auth 5] mmCIF format, chain FC [auth 7] mmCIF format, chain SL [auth g]	AB [auth 1], CL [auth 5], FC [auth 7], SL [auth g]	(3S,3'R,5R,6S,7cis)-7',8'-didehydro-5,6-dihydro-5,6-epoxy-beta,beta-carotene-3,3'-diol C₄₀ H₅₄ O₃ OGHZCSINIMWCSB-WMTIXGNLSA-N		Interactions Focus chain AB [auth 1] Focus chain CL [auth 5] Focus chain FC [auth 7] Focus chain SL [auth g] Interactions & Density Focus chain AB [auth 1] Focus chain CL [auth 5] Focus chain FC [auth 7] Focus chain SL [auth g]
BCR (Subject of Investigation/LOI) Query on BCR Download Ideal Coordinates CCD File SDF format, chain BG [auth h] SDF format, chain BJ [auth C] SDF format, chain CG [auth h] SDF format, chain EJ [auth c] SDF format, chain FG [auth m] SDF format, chain GB [auth 1] SDF format, chain II [auth d] SDF format, chain JD [auth B] SDF format, chain KD [auth B] SDF format, chain ME [auth M] SDF format, chain MI [auth C] SDF format, chain PC [auth A] SDF format, chain QF [auth b] SDF format, chain RF [auth b] SDF format, chain SJ [auth c] SDF format, chain VD [auth H] SDF format, chain WE [auth a] SDF format, chain XH [auth D] MOL2 format, chain BG [auth h] MOL2 format, chain BJ [auth C] MOL2 format, chain CG [auth h] MOL2 format, chain EJ [auth c] MOL2 format, chain FG [auth m] MOL2 format, chain GB [auth 1] MOL2 format, chain II [auth d] MOL2 format, chain JD [auth B] MOL2 format, chain KD [auth B] MOL2 format, chain ME [auth M] MOL2 format, chain MI [auth C] MOL2 format, chain PC [auth A] MOL2 format, chain QF [auth b] MOL2 format, chain RF [auth b] MOL2 format, chain SJ [auth c] MOL2 format, chain VD [auth H] MOL2 format, chain WE [auth a] MOL2 format, chain XH [auth D] mmCIF format, chain BG [auth h] mmCIF format, chain BJ [auth C] mmCIF format, chain CG [auth h] mmCIF format, chain EJ [auth c] mmCIF format, chain FG [auth m] mmCIF format, chain GB [auth 1] mmCIF format, chain II [auth d] mmCIF format, chain JD [auth B] mmCIF format, chain KD [auth B] mmCIF format, chain ME [auth M] mmCIF format, chain MI [auth C] mmCIF format, chain PC [auth A] mmCIF format, chain QF [auth b] mmCIF format, chain RF [auth b] mmCIF format, chain SJ [auth c] mmCIF format, chain VD [auth H] mmCIF format, chain WE [auth a] mmCIF format, chain XH [auth D]	BG [auth h] BJ [auth C] CG [auth h] EJ [auth c] FG [auth m] BG [auth h], BJ [auth C], CG [auth h], EJ [auth c], FG [auth m], GB [auth 1], II [auth d], JD [auth B], KD [auth B], ME [auth M], MI [auth C], PC [auth A], QF [auth b], RF [auth b], SJ [auth c], VD [auth H], WE [auth a], XH [auth D]	BETA-CAROTENE C₄₀ H₅₆ OENHQHLEOONYIE-JLTXGRSLSA-N		Interactions Focus chain BG [auth h] Focus chain BJ [auth C] Focus chain CG [auth h] Focus chain EJ [auth c] Focus chain FG [auth m] Focus chain GB [auth 1] Focus chain II [auth d] Focus chain JD [auth B] Focus chain KD [auth B] Focus chain ME [auth M] Focus chain MI [auth C] Focus chain PC [auth A] Focus chain QF [auth b] Focus chain RF [auth b] Focus chain SJ [auth c] Focus chain VD [auth H] Focus chain WE [auth a] Focus chain XH [auth D] Interactions & Density Focus chain BG [auth h] Focus chain BJ [auth C] Focus chain CG [auth h] Focus chain EJ [auth c] Focus chain FG [auth m] Focus chain GB [auth 1] Focus chain II [auth d] Focus chain JD [auth B] Focus chain KD [auth B] Focus chain ME [auth M] Focus chain MI [auth C] Focus chain PC [auth A] Focus chain QF [auth b] Focus chain RF [auth b] Focus chain SJ [auth c] Focus chain VD [auth H] Focus chain WE [auth a] Focus chain XH [auth D]
LMU (Subject of Investigation/LOI) Query on LMU Download Ideal Coordinates CCD File SDF format, chain BI [auth D] SDF format, chain IL [auth 5] SDF format, chain JL [auth g] SDF format, chain PH [auth 8] SDF format, chain SC [auth A] SDF format, chain TK [auth 5] SDF format, chain WG [auth 2] SDF format, chain YE [auth a] SDF format, chain YL [auth g] MOL2 format, chain BI [auth D] MOL2 format, chain IL [auth 5] MOL2 format, chain JL [auth g] MOL2 format, chain PH [auth 8] MOL2 format, chain SC [auth A] MOL2 format, chain TK [auth 5] MOL2 format, chain WG [auth 2] MOL2 format, chain YE [auth a] MOL2 format, chain YL [auth g] mmCIF format, chain BI [auth D] mmCIF format, chain IL [auth 5] mmCIF format, chain JL [auth g] mmCIF format, chain PH [auth 8] mmCIF format, chain SC [auth A] mmCIF format, chain TK [auth 5] mmCIF format, chain WG [auth 2] mmCIF format, chain YE [auth a] mmCIF format, chain YL [auth g]	BI [auth D] IL [auth 5] JL [auth g] PH [auth 8] SC [auth A] BI [auth D], IL [auth 5], JL [auth g], PH [auth 8], SC [auth A], TK [auth 5], WG [auth 2], YE [auth a], YL [auth g]	DODECYL-ALPHA-D-MALTOSIDE C₂₄ H₄₆ O₁₁ NLEBIOOXCVAHBD-YHBSTRCHSA-N		Interactions Focus chain BI [auth D] Focus chain IL [auth 5] Focus chain JL [auth g] Focus chain PH [auth 8] Focus chain SC [auth A] Focus chain TK [auth 5] Focus chain WG [auth 2] Focus chain YE [auth a] Focus chain YL [auth g] Interactions & Density Focus chain BI [auth D] Focus chain IL [auth 5] Focus chain JL [auth g] Focus chain PH [auth 8] Focus chain SC [auth A] Focus chain TK [auth 5] Focus chain WG [auth 2] Focus chain YE [auth a] Focus chain YL [auth g]
BCT (Subject of Investigation/LOI) Query on BCT Download Ideal Coordinates CCD File SDF format, chain CI [auth d] SDF format, chain RH [auth D] MOL2 format, chain CI [auth d] MOL2 format, chain RH [auth D] mmCIF format, chain CI [auth d] mmCIF format, chain RH [auth D]	CI [auth d], RH [auth D]	BICARBONATE ION C H O₃ BVKZGUZCCUSVTD-UHFFFAOYSA-M		Interactions Focus chain CI [auth d] Focus chain RH [auth D] Interactions & Density Focus chain CI [auth d] Focus chain RH [auth D]
FE2 (Subject of Investigation/LOI) Query on FE2 Download Ideal Coordinates CCD File SDF format, chain LI [auth d] SDF format, chain UH [auth D] MOL2 format, chain LI [auth d] MOL2 format, chain UH [auth D] mmCIF format, chain LI [auth d] mmCIF format, chain UH [auth D]	LI [auth d], UH [auth D]	FE (II) ION Fe CWYNVVGOOAEACU-UHFFFAOYSA-N		Interactions Focus chain LI [auth d] Focus chain UH [auth D] Interactions & Density Focus chain LI [auth d] Focus chain UH [auth D]
