9NGH | pdb_00009ngh

Cg10062 E114N mutant with acetylenecarboxylic acid

PDB DOI: https://doi.org/10.2210/pdb9NGH/pdb

Classification: HYDROLASE
Organism(s): Corynebacterium glutamicum
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2025-02-22 Released: 2025-04-02
Deposition Author(s): Silva, K., Nayebi, G.H., Geiger, J.H., Draths, K.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.92 ?
R-Value Free:
0.312 (Depositor), 0.308 (DCC)
R-Value Work:
0.252 (Depositor), 0.251 (DCC)
R-Value Observed:
0.258 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Cg10062 E114N mutant with acetylenecarboxylic acid

Silva, K., Geiger, J.H., Draths, K.

To be published.

Macromolecule Content

Total Structure Weight: 17 kDa
Atom Count: 1,216
Modelled Residue Count: 146
Deposited Residue Count: 148
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
4-oxalocrotonate tautomerase	A	148	Corynebacterium glutamicum	Mutation(s): 1 Gene Names: AUP69_07050, AUP70_06515
UniProt
Find proteins for A0A0S2T163 (Corynebacterium glutamicum) Explore A0A0S2T163 Go to UniProtKB: A0A0S2T163
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A0S2T163
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1BXY Query on A1BXY Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	prop-2-ynoic acid C₃ H₂ O₂ UORVCLMRJXCDCP-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.92 ?
R-Value Free: 0.312 (Depositor), 0.308 (DCC)
R-Value Work: 0.252 (Depositor), 0.251 (DCC)
R-Value Observed: 0.258 (Depositor)

Space Group: P 4₁ 3 2

Unit Cell:

Length ( ? )	Angle ( ? )
a = 146.162	α = 90
b = 146.162	β = 90
c = 146.162	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2025-04-02

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2025-04-02
Type: Initial release
