Download MendeleyPTCH1 in complex with Fab6H3
Hu, Q., Qi, X., Li, X.To be published.
9MS8 | pdb_00009ms8
PTCH1 in complex with Fab6H3
- PDB DOI: https://doi.org/10.2210/pdb9MS8/pdb
- EM Map EMD-48568: EMDB EMDataResource
- Classification: MEMBRANE PROTEIN/IMMUNE SYSTEM
- Organism(s): Homo sapiens, Mus musculus
- Expression System: Homo sapiens, Mus musculus
- Mutation(s): No
- Deposited: 2025-01-09 Released: 2025-04-02
- Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)
Experimental Data Snapshot
- Method: ELECTRON MICROSCOPY
- Resolution: 3.73 Å
- Aggregation State: PARTICLE
- Reconstruction Method: SINGLE PARTICLE
wwPDB Validation 3D Report Full Report
This is version 1.0 of the entry. See complete history.
Literature
Macromolecules
Find similar proteins by:
(by identity cutoff) | 3D Structure
Entity ID: 1 | |||||
|---|---|---|---|---|---|
| Molecule | Chains | Sequence Length | Organism | Details | Image |
| Protein patched homolog 1 | 1,094 | Homo sapiens | Mutation(s): 0 Gene Names: PTCH1, PTCH |  | |
UniProt & NIH Common Fund Data Resources | |||||
Find proteins for Q13635 (Homo sapiens) Explore Q13635 Go to UniProtKB: Q13635 | |||||
PHAROS: Q13635 GTEx: ENSG00000185920 | |||||
Entity Groups | |||||
| Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
| UniProt Group | Q13635 | ||||
Sequence AnnotationsExpand | |||||
| |||||
Find similar proteins by:
(by identity cutoff) | 3D Structure
Entity ID: 2 | |||||
|---|---|---|---|---|---|
| Molecule | Chains | Sequence Length | Organism | Details | Image |
| 6H3 Fab light chain | B [auth L] | 102 | Mus musculus | Mutation(s): 0 |  |
Entity Groups | |||||
| Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
Sequence AnnotationsExpand | |||||
| |||||
Find similar proteins by:
(by identity cutoff) | 3D Structure
Entity ID: 3 | |||||
|---|---|---|---|---|---|
| Molecule | Chains | Sequence Length | Organism | Details | Image |
| 6H3 Fab heavy chain | C [auth H] | 110 | Mus musculus | Mutation(s): 0 |  |
Entity Groups | |||||
| Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
Sequence AnnotationsExpand | |||||
| |||||
Experimental Data & Validation
Experimental Data
- Method: ELECTRON MICROSCOPY
- Resolution: 3.73 Å
- Aggregation State: PARTICLE
- Reconstruction Method: SINGLE PARTICLE
| Task | Software Package | Version |
|---|---|---|
| MODEL REFINEMENT | PHENIX | 1.21.2_5419: |
Entry History & Funding Information
Deposition Data
| Funding Organization | Location | Grant Number |
|---|---|---|
| National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS) | United States | R35GM149533 |
Revision History (Full details and data files)
- Version 1.0: 2025-04-02
Type: Initial release
